Switch PoE+ Stackeable Capa 3, 20 puertos 10/100/1000 Mbps + 4 x 100M/1G/2.5/5G-T + 4 puertos SFP+ 10 G, hasta 740 W, fuente redundante

Marca: ALLIED TELESIS
Modelo: AT-X530-28GPXM-10
Clave: 166715
Clave SAT: 43222610
162,188.72 202,735.89 (impuesto incluido)

Descripción del producto

Switch PoE+ Stackeable Capa 3, 20 puertos 10/100/1000 Mbps + 4 x 100M/1G/2.5/5G-T + 4 puertos SFP+ 10 G, hasta 740 W, fuente redundante

Switch PoE+ Stackeable Capa 3, 20 puertos 10/100/1000 Mbps + 4 x 100M/1G/2.5/5G-T + 4 puertos SFP+ 10 G, hasta 740 W, fuente redundante

Potentes Switches Multi-Gigabit

Redes Totalmente Autónomas

Puertos

  • 20 puertos 10/100/1000 Mbps
  • 4 puertos 100M/1G/2.5G/5G
  • 4 puertos SFP+ 10 G (2 sí son stacked)
  • Forwarding rate: 119 Millones de paquetes por segundo (Mpps)
  • Switching fabric: 160 Gbps

PoE

  • IEEE 802.3af Power Over Ethernet (PoE) hasta 15.4 W por puerto
  • IEEE 802.3at Power Over Ethernet plus (PoE+) hasta 30 W por puerto
  • Potencia total: 370 W (1 fuente de poder) / 740 W (2 fuentes de poder)

Sistema operativo

  • AlliedWare Plus™

Administración

  • Interfaz de línea de comandos (CLI)
  • Telnet
  • SSH
  • Monitoreo SNMP v1, v2c & v3

Características generales

  • Voice VLAN
  • VLAN Mirroring (RSPAN)
  • Access Control Lists (ACLs)
  • VLAN ACLs
  • Storm protection
  • Loop protection
  • Soporte de Multicast -IGMP snooping (v1, v2 and v3)
  • Tri-authentication

QoS (Quality of Service)

  • 8 colas de prioridad
  • Limite el ancho de banda por puerto o por clase de tráfico

Protocolos de ruteo

  • Ruteo estático
  • Border Gateway Protocol (BGP)
  • Routing Information Protocol (RIP)
  • Open Shortest Path First (OSPFv3)
  • Licencia de Capa 3 Premium AT-FL-X530-01

Características de redundancia

  • G.8032 Ethernet Ring Protection
  • Ethernet Protection Switched Ring (EPSRing)
  • Multiple Spanning Tree Protocol (MSTP)
  • Rapid Spanning Tree Protocol (RSTP)

Características físicas y eléctricas

  • Alimentación: 100-240 VAC, 50-60 Hz
  • Dimensiones: 1 U Rack, 44 x 421 x 441 mm
  • Peso: 8.3 kg
  • Temperatura de Operación: 0 a 50° C

Garantía

  • 1 año

Ejemplo de una red empresarial de alto desempeño

Descargas e información del producto

Lo sentimos, en este momento no contamos con descargas disponibles para este producto.
